Impeller Pump

Flow Meter

Spreading System

Spreader 2

Spread Tank

M3 Aircraft Arm

Spray Lance

Aerial Electronics Module

Front Frame 1




        No.
        EE Group Item ID
        Material Number
        Material Name


        1
        DJIAGT25P-R21
        YC.JG.ZS004476.05
        Front Shell_Front Cover


        2
        DJIAGT100-R313
        YC.WJ.L00870.02
        Screw M30-HC060060-55-85


        3
        DJIAGT50-R279
        YC.JG.ZS003452.04
        Outer Shell Side Cover


        4
        DJIAGT100-R313
        YC.WJ.L00870.02
        Screw M30-HC060060-55-85


        5
        DJIAGT25P-R22
        YC.JG.ZS004477.05
        Front Shell Module


        6
        DJIAGT100-R313
        YC.WJ.L00870.02
        Screw M30-HC060060-55-85


        8
        DJIAGT50-R82
        YC.DZ.AA000326.02
        SDR Antenna (Front)


        9
        DJIAGT50-R188
        YC.JG.ZS003455.02
        RF Cable Clip


        10
        DJIDLYFC30-R24
        YC.ST.LL000235.01
        T30-HC00800080-057030-5103-N


        11
        DJIAGT40-R253
        YC.JG.ZS000998.06
        Buckle Base (Female)


        12
        DJIDLYFC30-R24
        YC.ST.LL000235.01
        T30-HC00800080-057030-5103-N






Front Frame 2




        No.
        EE Group Item ID
        Material Number
        Material Name


        1
        DJIAGT25P-R34
        YC.JG.ZS004593.04
        Front Shell_Top Cover


        2
        DJIAGT100-R313
        YC.WJ.L00870.02
        Screw M30-HC060060-55-85


        3
        DJIAGT100-R314
        YC.WJ.L00868.02
        Screw M30-HC080080-55-85


        4
        DJIAGT25P-R111
        BC.AG.SS000863.01
        FPV Module (Incl. Signal Cable)


        5
        DJIAGT100-R313
        YC.WJ.L00870.02
        Screw M30-HC060060-55-85


        6
        DJIAGT50-R168
        YC.ST.LL000122.01
        Screw M25-HC00780040-040020-5108-N


        7
        DJIAGT25P-R112
        YC.XC.XX001215.06
        FPV Camera Signal Cable


        8
        DJIAGT70P-R35
        YC.JG.MQ002494.02
        Thermally Conductive Pad (71 x 51 mm)


        9
        DJIAGT70P-R36
        YC.JG.MQ002497.01
        Thermally Conductive Pad (35 x 27 mm)


        10
        DJIAGT25P-R60
        YC.JG.YZ000805.07
        Front Radar Bracket


        11
        DJIAGT100-R97
        YC.ST.LL000489.03
        Screw M50-HC02000200-087052-4203-Y


        12
        DJIAGT25P-R33
        YC.JG.ZS004582.03
        Front Radar Base Bracket


        13
        DJIAGT100-R313
        YC.WJ.L00870.02
        Screw M30-HC060060-55-85


        14
        DJIAGT100-R313
        YC.WJ.L00870.02
        Screw M30-HC060060-55-85


        15
        DJIAGT100-R313
        YC.WJ.L00870.02
        Screw M30-HC060060-55-85


        16
        DJIAGT50-R199
        YC.JG.MY001041.02
        Radar Sealing Ring


        17
        DJIAGT25P-R44
        YC.JG.YZ000803.02
        Front Radar Base


        18
        DJIAGT25P-R04
        BC.AG.SS001004.02
        Front Radar Module (Incl. Signal Cable)


        19
        DJIAGT25P-R61
        YC.XC.XX001212.06
        Front Radar Signal Cable


        20
        DJIAGT50-R124
        YC.ST.LL000226.01
        M30-HC01450080-100020-5103-Y


        21
        DJIAGT50-R193
        YC.JG.ZS003453.03
        Propulsion Cable Clip


        22
        DJIAGT100-R311
        YC.WJ.L00873.02
        Screw M30-HC1880-55-85


        23
        DJIAGT50-R168
        YC.ST.LL000122.01
        Screw M25-HC00780040-040020-5108-N


        25
        DJIAGT25P-R62
        YC.XC.XX001214.08
        Binocular Vision Sensor Signal Cable


        26
        DJIAGT25P-R63
        YC.JG.ZS005366.02
        Female Connector Rubber Stopper


        27
        DJIAGT50-R168
        YC.ST.LL000122.01
        Screw M25-HC00780040-040020-5108-N


        28
        DJIAGT25P-R40
        YC.ST.LL000541.01
        Screw M30-HC02380080-094020-5103-Y


        29
        DJIAGT70P-R39
        YC.JG.MY001353.04
        Binocular Vision Sensor Damping Pad


        30
        DJIAGT25P-R64
        YC.JG.MQ002156.02
        Duct Tape


        31
        DJIAGT25P-R65
        BC.AG.SS000873.01
        Binocular Fisheye Sensor (Incl. Signal Cable)


        32
        DJIAGT25P-R66
        YC.XC.XX001208.05
        Payload Adapter Cable


        33
        DJIAGT70P-R26
        YC.JG.MY001453.05
        Cable Rubber Stopper


        34
        DJIAGT50-R42
        YC.ST.LL000148.01
        M40-HC01400140-070039-4105-Y


        35
        DJIAGT50-R187
        YC.JG.MY001079.03
        Front Shell Sealing Stopper


        36
        DJIAGT25P-R67
        YC.JG.MY001490.01
        Front Shell Rubber Stopper


        37
        DJIAGT25P-R68
        YC.JG.MQ002641.02
        Sealing Foam (133.3 x 35.7 mm)


        38
        DJIAGT25P-R69
        YC.JG.ZS004478.06
        Front Shell Bottom Plate


        39
        DJIAGT25P-R70
        YC.JG.MQ002642.02
        Sealing Foam (59.5 x 19.3 mm)





Middle Frame




        No.
        EE Group Item ID
        Material Number
        Material Name


        1
        DJIAGT50-R25
        YC.JG.ZS003467.07
        Landing Gear Fixing Piece (Rear Right)


        2
        DJIAGT25P-R35
        YC.ST.LL000482.02
        Screw M40-HC01400140-070042-4203-Y


        3
        DJIAGT50-R247
        YC.JG.MY001051.04
        Cable Tube Rubber Stopper


        4
        DJIAGT25-R18
        YC.JG.MY001050.05
        Anti-Collision Pad


        5
        DJIAGT25P-R71
        YC.JG.ZS004996.03
        Hose Clip


        6
        DJIAGT25P-R35
        YC.ST.LL000482.02
        Screw M40-HC01400140-070042-4203-Y


        7
        DJIAGT25-R34
        YC.JG.ZS003413.04
        Aircraft Arm Fixing Piece (Right)


        8
        DJIAGT50-R251
        YC.JG.ZS003602.03
        Weighing Sensor Bracket Roller


        9
        DJIAGT50-R217
        YC.WJ.ZZ002618.02
        Spray Tank Fixing Piece_Roller Shaft


        10
        DJIAGT50-R276
        YC.JG.ZS003599.05
        Weight Sensor Bracket (Right)


        11
        DJIAGT100-R306
        YC.WJ.LL000232.02
        M40-HC01000100-072028-5103-N_01


        12
        DJIAGT25P-R72
        BC.AG.SS000864.01
        Aircraft Frame Module


        13
        DJIAGT50-R22
        YC.JG.ZS003464.07
        Landing Gear Fixing Piece (Front Right)


        14
        DJIAGT50-R288
        YC.JG.ZS004978.02
        Extended Battery Supporting Piece (Right)


        15
        DJIAGT50-R127
        YC.JG.MQ001386.01
        Battery Supporting Piece Patch (Right)


        16
        DJIAGT25P-R12
        YC.JG.MY001402.01
        Outer Scroll Wheel（Small)


        17
        DJIAGT50-R167
        YC.XJ.QT000247.03
        Battery Fixing Piece_External Roller


        18
        DJIAGT50-R165
        YC.SJ.WS002500.02
        Spray Tank Fixing Piece_Internal Roller


        19
        DJIAGT50-R217
        YC.WJ.ZZ002618.02
        Spray Tank Fixing Piece_Roller Shaft


        20
        DJIAGT50-R207
        YC.JG.ZS004993.01
        Inner Scroll Wheel（Small)


        21
        DJIAGT50-R210
        YC.ST.LL000480.01
        Screw T20-PR01450045-035015-5103-N


        22
        DJIAGT25-R31
        YC.JG.JS000034.04
        Cable Tube


        23
        DJIAGT25P-R36
        YC.ST.LL000483.02
        Screw M40-HC01000100-072042-4203-Y


        24
        DJIAGT50-R126
        YC.JG.MQ001385.01
        Battery Supporting Piece Patch (Left)


        25
        DJIAGT50-R287
        YC.JG.ZS004979.02
        Extended Battery Supporting Piece (Left)


        26
        DJIAGT50-R23
        YC.JG.ZS003465.07
        Landing Gear Fixing Piece (Front Left)


        27
        DJIAGT50-R143
        YC.JG.ZS003589.04
        Cable Clip


        28
        DJIAGT50-R272
        YC.JG.ZS003601.06
        Weighing Sensor Bracket (Front)


        29
        DJIAGT50-R277
        YC.JG.ZS003600.05
        Weight Sensor Bracket (Left)


        30
        DJIAGT50-R130
        YC.JG.ZS002229.04
        Load Sensor Cable Clip


        31
        DJIAGT25-R33
        YC.JG.ZS003412.04
        Aircraft Arm Fixing Piece (Left)


        32
        DJIAGT50-R24
        YC.JG.ZS003466.07
        Landing Gear Fixing Piece (Rear Left)


        33
        DJIAGT25P-R56
        YC.ST.LM000092.01
        Nut (M40-HN068100-5103)


        34
        DJIAGT25P-R39
        YC.ST.LL000537.01
        Screw (M40-HC04000140-070040-5103-N)





Rear Frame




        No.
        EE Group Item ID
        Material Number
        Material Name


        1
        DJIAGT50-R31
        YC.JG.ZS003395.05
        Rear Shell Bottom Plate


        2
        DJIAGT50-R42
        YC.ST.LL000148.01
        M40-HC01400140-070039-4105-Y


        3
        DJIAGT25P-R73
        YC.JG.MY001071.03
        Dustproof Stopper


        4
        DJIAGT50-R190
        YC.JG.MY001128.01
        Cable Rubber Sleeve


        5
        DJIAGT25P-R74
        YC.JG.ZS004834.03
        Cable Clip


        6
        DJIAGT100-R306
        YC.WJ.LL000232.02
        M40-HC01000100-072028-5103-N_01


        7
        DJIAGT100-R313
        YC.WJ.L00870.02
        Screw M30-HC060060-55-85


        8
        DJIAGT100-R313
        YC.WJ.L00870.02
        Screw M30-HC060060-55-85


        9
        DJIAGT50-R279
        YC.JG.ZS003452.04
        Outer Shell Side Cover


        10
        DJIAGT50-R29
        YC.JG.ZS003397.05
        Rear Shell Module


        11
        DJIAGT50-R205
        YC.JG.MY001054.01
        Damping Pad


        12
        DJIAGT50-R171
        YC.ST.LL000335.02
        Screw M30-HC01350050-140020-5103-Y


        13
        DJIAGT25-R42
        BC.AG.SS000695.02
        Power Distribution Board Module


        14
        DJIAGT50-R286
        YC.JG.FM000122.04
        Battery Buckle


        15
        DJIAGT50-R177
        YC.ST.LL000336.01
        Screw (M30-HC100100-55-85)


        16
        DJIAGT50-R284
        YC.JG.ZS003588.05
        Power Distribution Board Waterproof Cover


        17
        DJIAGT50-R183
        YC.ST.LL000382.01
        Screw (M30-HC00550045-055012-5103-Y)


        18
        DJIAGT50-R204
        YC.JG.MY001073.04
        RTK Rubber Ring


        19
        DJIAGT100-R259
        BC.AG.SS001034.01
        RTK Antenna Module


        20
        DJIAGT50-R30
        YC.JG.ZS003396.06
        Rear Cover of Rear Shell


        21
        DJIAGT100-R313
        YC.WJ.L00870.02
        Screw M30-HC060060-55-85


        22
        DJIAGT100-R313
        YC.WJ.L00870.02
        Screw M30-HC060060-55-85


        23
        DJIAGT50-R32
        YC.JG.ZS003443.08
        Rear Shell_Lower Cover





Cable Distribution Board




        No.
        EE Group Item ID
        Material Number
        Material Name


        1
        DJIAGT25P-R75
        BC.AG.SS000861.01
        Payload Control Board


        2
        DJIAGT70P-R17
        YC.JG.QX002311.02
        Damping Pad A


        3
        DJIAGT100-R299
        YC.JG.QX002312.02
        Damping Pad B


        4
        DJIAGT100-R238
        YC.JG.MQ002623.03
        Thermally Conductive Pad (53.1 x 12.9 mm)


        5
        DJIAGT70P-R16
        YC.JG.MQ002463.02
        Thermally Conductive Pad (125.35 x 27.7 mm)


        6
        DJIAGT70P-R19
        YC.JG.MY001348.02
        Aerial-Electronics Module Sealing Ring


        7
        DJIAGT100-R314
        YC.WJ.L00868.02
        Screw M30-HC080080-55-85


        8
        DJIAGT25P-R76
        BC.AG.SS001138.01
        Aerial-Electronics System Module


        9
        DJIAGT70P-R15
        YC.JG.MY001349.04
        Barometer Curve Connector


        10
        DJIAGT50-R168
        YC.ST.LL000122.01
        Screw M25-HC00780040-040020-5108-N


        11
        DJIAGT50-R119
        YC.WJ.LL000235.02
        M20-HPW00600060-065016-5103-Y_02


        12
        DJIAGT50-R168
        YC.ST.LL000122.01
        Screw M25-HC00780040-040020-5108-N


        13
        DJIAGT50-R218
        YC.JG.MY000389.05
        Type-C Port Waterproof Cover





Propeller




        No.
        EE Group Item ID
        Material Number
        Material Name


        1
        DJIAGT25P-R43
        YC.JG.ZS005565.02
        Teflon Pad


        2
        DJIAGT50-R120
        YC.ST.LL000209.02
        M50-HF01430102-116041-0003-Y


        4
        DJIAGT25-R26
        YC.JG.QX002975.03
        Propeller Clamp


        5
        DJIAGT25-R02
        YC.JG.ZS003553.02
        Propeller (CW)


        6
        DJIAGT25-R01
        YC.JG.ZS003552.02
        Propeller (CCW)


        7
        DJIAGT25-R23
        YC.JG.MQ002005.01
        Propeller Fixing Piece





Cables




        No.
        EE Group Item ID
        Material Number
        Material Name


        1
        DJIAGT25P-R78
        YC.XC.DD000683.05
        Battery Power Cable


        2
        DJIAGT25P-R79
        YC.XC.XX001198.05
        Throttle Cable


        3
        DJIAGT25P-R80
        YC.XC.DD000680.04
        Rear Aircraft Arm ESC Power Adapter Cable


        4
        DJIAGT25P-R81
        YC.XC.XX001195.04
        Battery Communication Cable


        5
        DJIAGT25P-R82
        YC.XC.TT000179.05
        RF Coaxial Cable


        6
        DJIAGT25P-R83
        YC.DZ.AA000460.02
        SDR Antenna (Rear)


        7
        DJIAGT50-R254
        YC.JG.MY001011.05
        Weighing Sensor Rubber Cover


        8
        DJIAGT25P-R84
        YC.XC.XX001213.06
        Beacon Signal Cable


        9
        DJIAGT25P-R79
        YC.XC.XX001198.05
        Throttle Cable


        10
        DJIAGT25P-R80
        YC.XC.DD000680.04
        Rear Aircraft Arm ESC Power Adapter Cable


        11
        DJIAGT25P-R82
        YC.XC.TT000179.05
        RF Coaxial Cable


        12
        DJIAGT25P-R83
        YC.DZ.AA000460.02
        SDR Antenna (Rear)


        13
        DJIAGT25P-R85
        BC.AG.SS000860.01
        Weight Sensor Module





Landing Gear




        No.
        EE Group Item ID
        Material Number
        Material Name


        1
        DJIAGT100-R313
        YC.WJ.L00870.02
        Screw M30-HC060060-55-85


        2
        DJIAGT25P-R86
        BC.AG.SS000877.01
        Beacon


        3
        DJIAGT25P-R01
        YC.JG.ZS004578.04
        Beacon Bracket


        4
        DJIAGT100-R311
        YC.WJ.L00873.02
        Screw M30-HC1880-55-85


        5
        DJIAGT50-R163
        YC.WJ.L00877.00
        M3 Nut


        6
        DJIAGT100-R311
        YC.WJ.L00873.02
        Screw M30-HC1880-55-85


        7
        DJIAGT25P-R87
        YC.JG.ZS005117.01
        Landing Gear Cable Clip B


        8
        DJIAGT100-R92
        YC.ST.LL000543.01
        Screw T30-HC01000100-057030-5103-N


        9
        DJIAGT30-R71
        YC.WJ.L00871.02
        Screw M30-HC100100-55-85


        10
        DJIAGT50-R163
        YC.WJ.L00877.00
        M3 Nut


        11
        DJIAGT50-R280
        YC.JG.ZS003558.04
        Bottom Rubber Pad


        12
        DJIAGT25P-R38
        YC.JG.ZS005273.04
        Landing Gear Crossbeam (Rear)


        13
        DJIAGT50-R221
        YC.JG.ZS003725.04
        Landing Gear Cable Clip


        14
        DJIAGT100-R92
        YC.ST.LL000543.01
        Screw T30-HC01000100-057030-5103-N


        15
        DJIAGT50-R168
        YC.ST.LL000122.01
        Screw M25-HC00780040-040020-5108-N


        16
        DJIAGT25-R15
        YC.XC.XX001216.07
        Rear Radar Signal Cable


        17
        DJIAGT70P-R91
        YC.JG.MY001131.01
        Rubber Pad


        18
        DJIAGT100-R313
        YC.WJ.L00870.02
        Screw M30-HC060060-55-85


        19
        DJIAGT100-R311
        YC.WJ.L00873.02
        Screw M30-HC1880-55-85


        20
        DJIAGT70P-R92
        YC.JG.ZS004711.05
        Radar Supporting Piece (Left)


        21
        DJIAGT25P-R05
        BC.AG.SS001005.02
        Rear Radar Module (Incl. Signal Cable)


        22
        DJIAGT70P-R90
        YC.JG.MY001575.02
        Anti-Wear Rubber Stopper


        23
        DJIAGT50-R174
        YC.JG.ZS003492.05
        Radar Supporting Piece (Right)


        24
        DJIAGT100-R311
        YC.WJ.L00873.02
        Screw M30-HC1880-55-85


        25
        DJIAGT25P-R15
        YC.JG.BJ002268.04
        Landing Gear Aluminum Tube





Tank 1


        No.
        EE Group Item ID
        Material Number
        Material Name

        1
        DJIAGT25P-R02
        YC.JG.CS000017.08
        Spray Tank (20L)

Tank 2




        No.
        EE Group Item ID
        Material Number
        Material Name


        1
        DJIAGT50-R105
        YC.BZ.RB000011.04
        Spread Tank Lanyard


        2
        DJIAGT100-R284
        YC.JG.ZS002250.03
        Spray Tank Cover Waterproof Permeability Cover


        3
        DJIAGT100-R304
        YC.JG.MY000678.02
        Spray Tank Cover Waterproof Permeability Film


        4
        DJIAGT50-R226
        YC.JG.MY000679.02
        Spray Tank Cover Sealing Ring


        5
        DJIAGT50-R236
        YC.JG.ZS003393.05
        Spray Tank Cable Clip


        6
        DJIAGT50-R164
        YC.WJ.L00876.02
        Screw M40-HC060060-55-85


        7
        DJIAGT50-R164
        YC.WJ.L00876.02
        Screw M40-HC060060-55-85


        8
        DJIAGT50-R285
        YC.JG.ZS003392.02
        Impeller Pump Bracket


        9
        DJIAGT100-R295
        YC.JG.MY000687.06
        Spray Tank Y-tee Part Sealing Ring


        10
        DJIAGT100-R282
        YC.JG.ZS002232.07
        Spray Tank Y-tee Part


        11
        DJIAGT40-R114
        BC.AG.SS000471.01
        Spray Tank Liquid Level Meter


        12
        DJIAGT50-R121
        YC.JG.ZS002237.04
        Liquid Level Gauge Bracket


        13
        DJIAGT50-R164
        YC.WJ.L00876.02
        Screw M40-HC060060-55-85


        14
        DJIAGT50-R257
        YC.SJ.WS002412.03
        Spray Tank_Liquid Level Meter Installation Nut


        15
        DJIAGT50-R213
        YC.XJ.QT000194.02
        Spray Tank_Liquid Level Meter Installation Nut Sealing Ring


        16
        DJIAGT50-R334
        BC.AG.SS000709.01
        Liquid Level Gauge Sensor Module


        18
        DJIAGT25P-R88
        YC.JG.ZS005365.03
        Male Connector Rubber Stopper


        19
        DJIAGT100-R295
        YC.JG.MY000687.06
        Spray Tank Y-tee Part Sealing Ring


        20
        DJIAGT50-R164
        YC.WJ.L00876.02
        Screw M40-HC060060-55-85


        21
        DJIAGT100-R130
        YC.JG.ZS004712.02
        Flow Meter Bracket


        22
        DJIAGT100-R274
        YC.JG.ZS005454.03
        Filter With 50 Holes


        23
        DJIAGT50-R228
        YC.JG.ZS002233.07
        Water Outlet Rotation Cover


        24
        DJIAGT100-R38
        YC.JG.ZS005453.05
        Spray Tank Y-tee Part Nut


        25
        DJIAGT100-R319
        YC.SJ.J01186.02
        Spray Tank_Filter Rubber Ring


        26
        DJIAGT50-R62
        YC.JG.MY000845.02
        Spray Tank Y-tee Part Sealing Ring


        27
        DJIAGT50-R65
        YC.JG.ZS001085.02
        Spray Tank Inlet Filter


        28
        DJIAGT30-R133
        YC.SJ.WS002423.02
        Spray Tank_Spray Tank Cover Ring


        29
        DJIAGT50-R161
        YC.WJ.LL000211.02
        M30-HC02050080-070020-5103-Y_01


        30
        DJIAGT50-R64
        YC.JG.ZS002251.03
        Spray Tank Cover





Impeller Pump




        No.
        EE Group Item ID
        Material Number
        Material Name


        1
        DJIAGT25P-R89
        YC.JG.ZS004649.06
        Pump Shell


        2
        DJIAGT40-R203
        YC.XJ.QT000350.01
        Pump_Connector Sealing Ring


        3
        DJIAGT50-R78
        YC.JG.ZS003420.01
        Impeller Pump Curving Connector


        4
        DJIAGT100-R413
        YC.JG.MY001327.04
        Ceramic Rubber Pad


        5
        DJIAGT100-R413
        YC.JG.FM000157.02
        Ceramic Gasket


        6
        DJIAGT25P-R90
        YC.JG.ZS004667.07
        Isolation Sleeve


        7
        DJIAGT100-R289
        YC.JG.MY001052.03
        Pump Sealing Ring


        8
        DJIAGT50-R81
        BC.AG.SS000710.01
        Impeller Pump Module


        9
        DJIAGT25P-R91
        YC.XC.XX001209.06
        Spray Tank Signal Cable


        10
        DJIAGT100-R77
        YC.JG.MY001315.01
        Sealing Ring (OD=31.4 mm)


        11
        DJIAGT100-R313
        YC.WJ.L00870.02
        Screw M30-HC060060-55-85


        12
        DJIAGT40-R30
        YC.JG.ZS002389.07
        Impeller Pump Protective Hood


        13
        DJIAGT25P-R30
        YC.ST.LL000454.02
        Screw M30-HC00630050-050013-5103-Y


        14
        DJIAGT50-R38
        BC.AG.SS000870.01
        Impeller Pump Motor


        15
        DJIAGT25P-R92
        YC.JG.MY001316.01
        Sealing Ring (OD=46.5 mm)


        16
        DJIAGT50-R228
        YC.JG.ZS002233.07
        Water Outlet Rotation Cover


        17
        DJIAGT100-R285
        YC.JG.MY001053.02
        Y-tee Part Sealing Pad








        No.
        EE Group Item ID
        Material Number
        Material Name


        1
        DJIAGT50-R271
        YC.JG.JS000033.07
        Flow Meter Water Outlet Hose


        2
        DJIAGT50-R241
        YC.JG.ZS003594.01
        Thumb Nut


        3
        DJIAGT25P-R93
        YC.JG.ZS004721.05
        One-Way Valve Core Straight Connector


        4
        DJIAGT40-R41
        YC.JG.ZS002255.02
        Hose Nut


        5
        DJIAGT50-R144
        YC.JG.MY001129.03
        One-Way Valve Sealing Ring


        6
        DJIAGT100-R358
        YC.JG.MY001329.05
        One-Way Valve Core Sealing Ring


        7
        DJIAGT25P-R94
        YC.JG.ZS005001.06
        One-Way Valve Core


        8
        DJIAGT25P-R95
        YC.JG.TT000210.04
        One-Way Valve Spring


        9
        DJIAGT25P-R96
        YC.JG.ZS004722.06
        One-Way Valve Core Curve Connector


        10
        DJIAGT50-R328
        YC.XC.XX001004.04
        Flow Meter Signal Cable


        11
        DJIAGT40-R41
        YC.JG.ZS002255.02
        Hose Nut


        12
        DJIAGT50-R87
        BC.AG.SS000927.01
        Flow Meter Module (Incl. Signal Cable)


        13
        DJIAGT50-R275
        YC.JG.JS000032.02
        Flow Meter Water Inlet Hose


        14
        DJIAGT50-R241
        YC.JG.ZS003594.01
        Thumb Nut





Flow Meter




        No.
        EE Group Item ID
        Material Number
        Material Name


        1
        DJIAGT25P-R47
        BC.AG.SS000867.01
        M3 Aircraft Arm (Rear Left)


        2
        DJIAGT25P-R19
        YC.JG.FP000039.04
        Motor Cover


        3
        DJIAGT25P-R97
        YC.XC.DD000678.09
        M3 & M4 Aircraft Arm ESC Composite Cable


        4
        DJIAGT50-R214
        YC.WJ.LL000213.02
        M30-HT01930060-110025-5103-Y


        6
        DJIAGT25P-R98
        YC.JG.ZS004019.02
        In-Position Detector Bracket


        7
        DJIAGT100-R306
        YC.WJ.LL000232.02
        M40-HC01000100-072028-5103-N_01


        8
        DJIAGT25P-R41
        YC.ST.LL000544.01
        Screw T25-HC00800080-045025-4203-N


        9
        DJIAGT40-R80
        YC.JG.LD000041.02
        Locking Piece Fixing Screw Bolt


        10
        DJIAGT40-R105
        YC.WJ.LM000044.01
        M60-HX100060-5103_01


        11
        DJIAGT25P-R99
        YC.JG.LD000045.02
        Aircraft Arm Fixing Screw Bolt


        12
        DJIAGT50-R241
        YC.JG.ZS003594.01
        Thumb Nut


        13
        DJIAGT40-R105
        YC.WJ.LM000044.01
        M60-HX100060-5103_01


        14
        DJIAGT25P-R100
        YC.JG.BJ002409.04
        E-Type Circlip (OD=6 mm)


        15
        DJIAGT50-R42
        YC.ST.LL000148.01
        M40-HC01400140-070039-4105-Y


        16
        DJIAGT50-R43
        YC.JG.QX003014.01
        Buckle Rotation Shaft


        17
        DJIAGT40-R65
        YC.JG.QX002089.01
        Locking Piece Aircraft Arm Shaft


        18
        DJIAGT50-R93
        YC.JG.TT000165.01
        Buckle Torsion Spring


        19
        DJIAGT25P-R20
        YC.JG.QX003942.02
        Locking Piece Connection Rod


        20
        DJIAGT50-R48
        BC.AG.SS000701.02
        Buckle Module


        21
        DJIAGT50-R40
        YC.JG.BJ003468.01
        Locking Piece Handle


        22
        DJIAGT50-R46
        YC.JG.QX004662.02
        Locking Piece_Handle Connecting Rod Shaft


        23
        DJIAGT50-R405
        YC.JG.ZS006831.02
        Locking Piece Handle Rubber Sleeve


        24
        DJIAGT100-R313
        YC.WJ.L00870.02
        Screw M30-HC060060-55-85


        25
        DJIAGT25P-R49
        BC.AG.SS000869.01
        ESC Module


        26
        DJIAGT50-R168
        YC.ST.LL000122.01
        Screw M25-HC00780040-040020-5108-N


        28
        DJIAGT25P-R25
        YC.JG.JS000045.07
        Aircraft Arm Hose


        29
        DJIAGT50-R134
        YC.ST.LL000208.01
        M20-TC00700060-033010-0004-Y


        30
        DJIAGT25P-R42
        YC.JG.ZS005501.01
        Motor Upper Cover


        31
        DJIAGT100-R97
        YC.ST.LL000489.03
        Screw M50-HC02000200-087052-4203-Y


        32
        DJIAGT25-R17
        YC.BZ.TZ001048.01
        Motor Sticker


        33
        DJIAGT25-R08
        BC.AG.SS000706.02
        10028 Propulsion Motor


        34
        DJIAGT50-R180
        YC.JG.ZS003460.01
        Hose Nut (M15)


        35
        DJIAGT25P-R13
        YC.JG.MY001465.04
        Aircraft Arm Rubber



        DJIAGT25P-R101
        YC.XC.DD000676.07
        M1 & M2 Aircraft Arm ESC Composite Cable



        DJIAGT25P-R45
        BC.AG.SS000865.01
        M1 Aircraft Arm (Front Right)



        DJIAGT25P-R46
        BC.AG.SS000866.01
        M2 Aircraft Arm (Front Left)



        DJIAGT25P-R48
        BC.AG.SS000868.01
        M4 Aircraft Arm (Rear Right)





M3 Aircraft Arm

Spray Lance




        No.
        EE Group Item ID
        Material Number
        Material Name


        1
        DJIAGT25P-R26
        YC.JG.ZS004506.04
        Spray Lance Shell


        2
        DJIAGT25-R56
        YC.JG.JS000043.05
        Sprinkler Soft Hose


        3
        DJIAGT25P-R50
        BC.AG.SS000871.02
        Solenoid Valve Module


        4
        DJIAGT25P-R37
        YC.JG.ZS004923.02
        Centrifugal Sprinkler Lower Disk


        5
        DJIAGT100-R267
        YC.JG.TT000203.05
        R-Type Pin


        6
        DJIAGT25P-R07
        YC.JG.MY001295.01
        Sealing Ring (ID=16.5 mm)


        7
        DJIAGT100-R137
        YC.JG.ZS004510.03
        Centrifugal Sprinkler Nut


        8
        DJIAGT25P-R27
        YC.JG.ZS004509.02
        Centrifugal Sprinkler Upper Disk


        9
        DJIAGT25P-R51
        BC.AG.SS000872.01
        Centrifugal Motor


        10
        DJIAGT50-R224
        YC.WJ.LL000138.01
        Screw M25-HC00400040-050020-0003-N


        11
        DJIAGT100-R313
        YC.WJ.L00870.02
        Screw M30-HC060060-55-85


        12
        DJIAGT25P-R08
        YC.JG.MY001296.02
        Sprinkler Funnel Sealing Ring


        13
        DJIAGT25P-R28
        YC.JG.ZS004512.04
        Sprinkler Funnel


        14
        DJIAGT50-R224
        YC.WJ.LL000138.01
        Screw M25-HC00400040-050020-0003-N


        15
        DJIAGT40-R76
        YC.JG.MY000704.06
        Motor Sealing Ring


        16
        DJIAGT25P-R29
        YC.JG.ZS004513.04
        Sprinkler Funnel Lower Shell


        17
        DJIAGT25P-R06
        YC.XC.XX001281.04
        Centrifugal Sprinkler Adapter Cable


        18
        DJIAGT100-R313
        YC.WJ.L00870.02
        Screw M30-HC060060-55-85





Aerial Electronics Module




        No.
        EE Group Item ID
        Material Number
        Material Name


        6

        YC.WJ.LL000304
        Screw M20-PC00400040-040010-3123-Y


        9
        DJIAGT100-R318
        YC.SJ.S00717.01
        Vent Trap


        10
        DJIAGT70P-R19
        YC.JG.MY001348.02
        Aerial-Electronics Module Sealing Ring


        11
        DJIAGT50-R166
        YC.PM.QT000137.02



        12
        DJIAGT30-R181
        YC.WJ.LL000396.03
        Screw (T20-PC00400040-040010-0323-N)


        13
        DJIAGT70P-R14
        BC.AG.PP000520.01
        Barometer Board


        14
        DJIAGT50-R129
        YC.JG.MY000699.02
        Barometer Module Sealing Ring


        15
        DJIAGT50-R244
        YC.JG.ZS002301.05
        Barometer Outer Shell


        16
        DJIAGT100-R314
        YC.WJ.L00868.02
        Screw M30-HC080080-55-85


        17
        DJIAGT100-R320
        YC.QT.QT000167.02
        Barometer Waterproof Permeability Film








        No.
        EE Group Item ID
        Material Number
        Material Name


        40
        DJIAGT50-R121
        YC.JG.ZS002237.04
        Liquid Level Gauge Bracket


        41
        DJIAGT100-R339
        YC.JG.TT000204.03
        Torsion Spring


        42
        DJIAGT100-R342
        YC.JG.ZS004556.04
        Lever 2


        43
        DJIAGT25P-R100
        YC.JG.BJ002409.04
        E-Type Circlip (OD=6 mm)


        44
        DJIAGT100-R350
        YC.JG.ZS004555.05
        Lever 1


        45
        DJIAGT50-R298
        YC.JG.QX003018.01
        Spread Tank Lock Button


        46
        DJIAGT50-R145
        YC.JG.TT000163.01
        Lock Button Spring


        47
        DJIAGT30-R249
        YC.BZ.XX000417.01
        Spray System_ Locking Device EVA Foam


        48
        DJIAGT50-R164
        YC.WJ.L00876.02
        Screw M40-HC060060-55-85


        49
        DJIAGT25P-R107
        YC.JG.MY001300.04
        Silicone Rubber Pad


        50
        DJIAGT100-R367
        YC.JG.ZS004913.03
        Cable Clip


        51
        DJIAGT25P-R31
        YC.JG.ZS004551.06
        Auger External Shell


        52
        DJIAGT25P-R108
        YC.JG.QX003604.07
        Spinner Disk Flange


        53
        DJIAGT25P-R109
        YC.ST.CT000101.01
        Bearing (OD=24 mm)


        54
        DJIAGT50-R71
        YC.ST.LL000327.03
        Screw (M40-HC01050056-070039-5103-Y)


        55
        DJIAGT25P-R110
        YC.JG.ZS004552.03
        Spinner Disk External Shell






Spreader 1




        No.
        EE Group Item ID
        Material Number
        Material Name


        1
        DJIAGT25P-R10
        YC.JG.MY001343.01
        Spinner Disk Shaft Sealing Ring


        2
        DJIAGT25P-R52
        BC.AG.SS000913.01
        Spinner Disk Motor


        3
        DJIAGT50-R71
        YC.ST.LL000327.03
        Screw (M40-HC01050056-070039-5103-Y)


        4
        DJIAGT25P-R09
        YC.JG.MY001342.02
        Motor Sealing Ring


        5
        DJIAGT100-R358
        YC.JG.MY001329.05
        One-Way Valve Core Sealing Ring


        6
        DJIAGT25P-R17
        YC.JG.QX003603.08
        Spinner Disk Shaft


        7
        DJIAGT25P-R102
        BC.AG.SS000916.01
        Shaft Sleeve Module


        8
        DJIAGT30-R71
        YC.WJ.L00871.02
        Screw M30-HC100100-55-85


        9
        DJIAGT25P-R103
        YC.ST.LL000469.01
        Screw YC.ST.LL000469.01


        10
        DJIAGT100-R364
        YC.JG.ZS004580.06
        Sensing Part


        12
        DJIAGT50-R164
        YC.WJ.L00876.02
        Screw M40-HC060060-55-85


        13
        DJIAGT25P-R104
        YC.JG.ZS005201.06
        Composite Cable Clip


        14
        DJIAGT50-R164
        YC.WJ.L00876.02
        Screw M40-HC060060-55-85


        15
        DJIAGT100-R370
        BC.AG.SS000914.01
        Material Detection Motor


        16
        DJIAGT100-R314
        YC.WJ.L00868.02
        Screw M30-HC080080-55-85


        17
        DJIAGT50-R283
        YC.SJ.WS001064.01
        Fixing Knob


        18
        DJIAGT100-R329
        YC.JG.MY000387.02
        Reduction Gearbox Motor Dustproof Cover


        19
        DJIAGT100-R326
        YC.JG.QX003649.01
        Medium Pin (22.2 mm)


        20
        DJIAGT100-R375
        YC.JG.QX003648.01
        Long Pin (29.4 mm)


        21
        DJIAGT100-R355
        YC.JG.QX003650.01
        Short Pin (17.6 mm)


        22
        DJIAGT100-R326
        YC.JG.QX003649.01
        Medium Pin (22.2 mm)


        23
        DJIAGT25P-R54
        BC.AG.SS000917.01
        Auger Sensor


        24
        DJIAGT25P-R58
        BC.AG.SS000918.01
        Large Auger


        25
        DJIAGT25P-R32
        YC.JG.ZS004554.06
        Auger Motor Base


        26
        DJIAGT25P-R105
        YC.ST.CG000012.08
        Swipe Bearing


        26.5
        DJIAGT100-R337
        YC.JG.MY001491.02
        4-pin Cable Sleeve


        27
        DJIAGT50-R71
        YC.ST.LL000327.03
        Screw (M40-HC01050056-070039-5103-Y)


        28
        DJIAGT100-R314
        YC.WJ.L00868.02
        Screw M30-HC080080-55-85


        29
        DJIAGT100-R314
        YC.WJ.L00868.02
        Screw M30-HC080080-55-85


        30
        DJIAGT25P-R88
        YC.JG.ZS005365.04
        Male Connector Rubber Stopper


        31
        DJIAGT25P-R106
        YC.XC.XX001205.08
        Spreading Signal Cable


        32
        DJIAGT100-R314
        YC.WJ.L00868.02
        Screw M30-HC080080-55-85


        33
        DJIAGT50-R71
        YC.ST.LL000327.03
        Screw (M40-HC01050056-070039-5103-Y)


        35
        DJIAGT25P-R53
        BC.AG.SS000915.01
        Auger Motor


        36
        DJIAGT25P-R09
        YC.JG.MY001342.02
        Motor Sealing Ring


        37
        DJIAGT50-R164
        YC.WJ.L00876.02
        Screw M40-HC060060-55-85


        38
        DJIAGT100-R338
        YC.JG.ZS004696.03
        Quick-Release Clamp


        39
        DJIAGT100-R362
        YC.JG.ZS004557.03
        Quick-Release Rod





Spreader 2




        No.
        EE Group Item ID
        Material Number
        Material Name


        1
        DJIAGT25P-R23
        YC.JG.ZS004482.04
        Fender


        2
        DJIAGT25P-R24
        YC.JG.ZS004483.04
        Spinner Disk


        3
        DJIAGT100-R267
        YC.JG.TT000203.05
        R-Type Pin


        4
        DJIAGT25P-R14
        YC.JG.FM000159.04
        Thumb Nu


        5
        DJIAGT25P-R11
        YC.JG.MY001344.05
        Spinner Disk Shaft Dustproof Sleeve


        6
        DJIAGT25P-R18
        YC.JG.QX003605.02
        Spinner Disk Bracket


        7
        DJIAGT50-R71
        YC.ST.LL000327.03
        Screw (M40-HC01050056-070039-5103-Y)





Spread Tank


        No.
        EE Group Item ID
        Material Number
        Material Name

        1
        DJIAGT25P-R16
        YC.JG.CS000027.09
        Spread Tank (30L)

        2
        DJIAGT25-R36
        YC.JG.ZS003496.04
        Spread Tank Cover
